Part No. |
Emitted Color |
Color Temperatue
Wavelength |
Luminous Intensity |
Forward Voltage |
Forward Current |
Viewing Angle |
|
ML-P50WW64SH504000 |
White |
5000-8000K |
4000-5000LM |
32-36V |
1600mA |
140° |
|
ML-P50WW34RH503000 |
Warm White |
2700-3400K |
3000-4000LM |
32-36V |
1600mA |
140° |
|
ML-P50WR14SH501500 |
Red |
620-630NM |
1500-2000LM |
22-28V |
1750mA |
140° |
|
ML-P50WY24SH501500 |
Yellow |
589-593NM |
1500-2000LM |
22-28V |
1750mA |
140° |
|
ML-P50WO74SH501500 |
Orange |
595-605NM |
1500-2000LM |
22-28V |
1750mA |
140° |
|
ML-P50WB34RH50500 |
Blue |
455-465NM |
500-1000LM |
32-36V |
1600mA |
140° |
|
ML-P50WG64RH503000 |
Green |
520-530NM |
3000-4000LM |
32-36V |
1600mA |
140° |
|
