Part No. |
Emitted Color |
Color Temperatue
Wavelength |
Luminous Intensity |
Forward Voltage |
Forward Current |
Viewing Angle |
|
ML-P30WW64SH302400 |
White |
5000-8000K |
2400-3000LM |
16-18V |
2000mA |
140° |
|
ML-P30WW34SH301800 |
Warm White |
2700-3400K |
1800-2400LM |
16-18V |
2000mA |
140° |
|
ML-P30WR14SH30900 |
Red |
620-630NM |
900-1200LM |
12-14V |
2100mA |
140° |
|
ML-P30WY24SH30900 |
Yellow |
589-593NM |
900-1200LM |
12-14V |
2100mA |
140° |
|
ML-P30WO74SH30900 |
Orange |
595-605NM |
900-1200LM |
12-14V |
2100mA |
140° |
|
ML-P30WB34SH30300 |
Blue |
455-465NM |
300-500LM |
16-18V |
2000mA |
140° |
|
ML-P30WG64SH302000 |
Green |
520-530NM |
2000-2400LM |
16-18V |
2000mA |
140° | |
