Part No. |
Emitted Color |
Color Temperatue
Wavelength |
Luminous Intensity |
Forward Voltage |
Forward Current |
Viewing Angle |
|
ML-P10WW64SH10800 |
White |
5000-8000K |
800-1000LM |
10-12V |
1000mA |
140° |
|
ML-P10WW34SH10600 |
Warm White |
2700-3400K |
600-800LM |
10-12V |
1000mA |
140° |
|
ML-P10WR14SH10300 |
Red |
620-630NM |
300-400LM |
6.5-7.5V |
1000mA |
140° |
|
ML-P10WY24SH10300 |
Yellow |
589-593NM |
300-400LM |
6.5-7.5V |
1000mA |
140° |
|
ML-P10WO74SH10300 |
Orange |
595-605NM |
300-400LM |
6.5-7.5V |
1000mA |
140° |
|
ML-P10WB34SH10100 |
Blue |
455-465NM |
100-200LM |
10-12V |
1000mA |
140° |
|
ML-P10WG64SH10600 |
Green |
520-530NM |
600-800LM |
10-12V |
1000mA |
140° |
|
