Part No. |
Emitted Color |
Color Temperatue
Wavelength |
Luminous Intensity |
Forward Voltage |
Forward Current |
Viewing Angle |
|
ML-P5WW64SH04320 |
White |
5000-8000K |
320-400LM |
6.5-7.5V |
700mA |
140° |
|
ML-P5WW34SH04250 |
Warm White |
2700-3400K |
250-300LM |
6.5-7.5V |
700mA |
140° |
|
ML-P5WR14SH04120 |
Red |
620-630NM |
120-160LM |
4.5-5.5V |
700mA |
140° |
|
ML-P5WY24SH04120 |
Yellow |
589-593NM |
120-160LM |
4.5-5.5V |
700mA |
140° |
|
ML-P5WO74SH04120 |
Orange |
595-605NM |
120-160LM |
4.5-5.5V |
700mA |
140° |
|
ML-P5WB34SH0440 |
Blue |
455-465NM |
40-80LM |
6.5-7.5V |
700mA |
140° |
|
ML-P5WG64SH04250 |
Green |
520-530NM |
250-300LM |
6.5-7.5V |
700mA |
140° |
|
